GC MS Gas Chromatograph With Mass Spectrometer

Model: LTL-MSQ8100



GC1120 gas chromatograph


Features and performance:

1. Control system: designed for monitoring and controlling the instrument via the computer.
2. Column Compartment/oven with superior thermal performance, multistage (10 ramps) programmed temperature control function. (supported by “control system”)
3. Advanced built-in data acquisition system , supporting real time instrument status monitoring, detection signal acquisition and PC control
4. Column oven accommodates up to 3 chromatographic columns, and supports quick heat-up and rapid cool-down with automated back-door opening.
5. Flexible sample introduction system: 3 sample injectors could be installed and operated simultaneously with independent temperature control.
6. High sensibility and stability detector.
7. 2 independent and analog signals output.
8. M6 software, compatible with GLP/FDA-21 CFR Part11 requirements and regulations. (electronic records and signatures)





Accessories:

Carrier Gas System + Sample Introduction System + Separation System + Temperature Control System + Detector
Carrier Gas System: air source/ purification and desiccation device/ flow rate control device
Sample Introduction System: sample injector
Separation System: chromatographic column(packed column and capillary column)
Temperature Control System (Column Oven): constant temperature and programmed temperature
Detector: FID/ TCD/ FPD/ NPD



Main technical parameters:



Model#t GC1120
Sample Introduction System sample injector and evaporation chamber
Column Oven Temperature range Ambient temperature+7°C~400°℃(in 1°℃
increment)
Temperature accuracy ±0.02C
Cooling time 40oC to 50°C in 8-10 min at 25°℃ ambient
Programmed
temperature setting
0.1°℃~40°C/min (in 1°C increment)
Program ramps 7ramps in total (10 ramps available with control
workstation)
Size(LWH) 284*280*241mm(inside)
Flame lonization Detector
(FID)
Detection limit 3x101g/s(Cia)
Best test result 3x101g/s(Ci6)
Drift 6x1013A/30min
Noise $5x101A
Linearity range z10
Thermal Conductivity
Detector
(TCD)
Sensitivity 25000mV,mL/mg(C16)
Baseline noise 20uv
Drift 60uV/h
Linearity range 104
Flame Photometric
Detector
(FPD)
Detection limit 8×101g/s(P); 8×1011g/s(S)
Drift 2×1011A/30min
Baseline noise 5×101A
Nitrogen-Phosphorus
Detector
(NPD)
Detection limit s5x10-12g/s(N)(Azobenzene)
≤5x10-13g/s(P)(Malathion)
